Matrox ConvertIP SRH

Single-channel RJ45 HDMI-to-IP transmitter/receiver
Matrox ConvertIP SRH is a compact, standalone ST 2110 and IPMX transmitter/receiver device. Featuring one RJ45 port, ConvertIP SRH is designed for 1G AV workflows and is optimal for an ultra-low latency experience. The device can receive power over Ethernet through its RJ45 connection, or it can be powered through an optional power supply unit. Both can be used simultaneously to deliver power redundancy.

Key features


• HDMI I/O
• 1G and 2.5G support over RJ45
• Transmit or receive IP signals from a single device
• Standardized Discovery and Routing – based on AMWA NMOS IS-04 and IS-05 specifications
• Fanless design for quiet cooling
• Power redundancy through PoE+ and locking AC power connector (optional power supply cable sold separately)
• Compact form factor mounts easily to the back of a monitor
• Web-based user interface for managing ConvertIP devices
• Complimentary ConvertIP Manager Windows application for simple commission and deployment

Transport formats

• IPMX ready
• Colibri codec for visually lossless transmission of compressed of media over 1G network
• Optional JPEG XS codec license for SMPTE ST 2110-22 support (up to 2 Gbps)
• Glass-to-glass latencies of 1ms achievable
