Channel Output Circuits
Channel Output Connectors
- Dante (RJ45), Euroblock (for mix output only)
Channel Output Characteristics
- Dante Primary & Secondary: CH1/Ch2/Ch3/Ch4/MIX
- Euroblock connector: MIX only @ -10dBV balanced 600 Ohms
Channel Output Signal to Noise Ratio
Channel Output Frequency Response
Channel Output Distortion
Dimensions (W x H x D)
- 16-17/32 x 1-47/64 x 9-27/32 inches (420mm x 44mm x 250mm)
Power
Warranty-Parts/Labor
Power consumption
Weight:
Display
- LED Indicators for Power, Antenna 1-8, Sync, Main, Remote, RF Level (5-level display), Audio level / mute, Mic battery, Register
Audio Inputs
- 1.9 GHz DECT (wireless mics) and Euroblock
Operating Ambient Temperature
- 32° F to 113°F (0°C to 45°C)
Audio Input Characteristics
- -10 dBV balanced 600 Ohms
Audio Input Frequency Response
Audio Input Distortion
Mix Output Connectors
- Dante Primary & Secondary or Euroblock
Mix Output Characteristics
- Dante Primary & Secondary or Euroblock -10 dBV Balanced 600 Ohms
Mix Output Signal to Noise Ratio
Mix Output Frequency Response
Mix Output Distortion
Antenna Connectors
- 8 x RJ45 (compatible cables: CAT5 / CAT5e / CAT6 straight)
- Wiring distance up to 656 feet (200 m)
Antenna Field Selection
- 4 Selectable Range settings (selectable via dip switches on front panel or using Panasonic's Operations Support software)
Extension Connector
- 1 x RJ45, for WX-SE200or WX-SE200DN Extension Receivers (sold separately)
