Atomos Shinobi Lineup: Every Model Compared — Which One Is Right for Your Rig?

The Atomos Shinobi isn't a single product — it's a family of on-camera monitors spanning multiple sizes, brightness levels, and connectivity options. Understanding the full lineup makes it clear which model fits your camera, your rig, and your production style.

🎬 Watch the full breakdown: Atomos Shinobi complete guide on Video Guys Live →

---

What All Shinobi Monitors Share

Every Shinobi monitor is built around the same core proposition: a bright, professional-grade IPS display with broadcast monitoring tools in a compact, lightweight form factor that won't unbalance your rig or drain your budget.

All models include:

• IPS panel — accurate color reproduction across wide viewing angles
• Monitoring tools — false color, waveform, vectorscope, focus peaking, zoom assist
• HDMI input — accepts signal from any HDMI-capable camera
• Headphone output — monitor embedded audio from the HDMI feed
• NP-F battery compatible — standard Sony-style batteries power every Shinobi

---

Shinobi — The 5-Inch Entry Point

The original Shinobi is a 5-inch 1000-nit IPS monitor. Compact enough to sit directly on a camera's hot shoe, light enough to use on a gimbal without counterweight adjustment.

Key specs:

• 5-inch IPS display, 1920×1080
• 1000 nits peak brightness — usable in partial shade, challenging in direct sunlight
• HDMI input (up to 4K/60)
• 3G-SDI loop-through on SDI models

Best for: Mirrorless and DSLR shooters who want a larger reference monitor than their camera's built-in LCD, gimbal operators where weight is critical, run-and-gun shooters who need a compact monitor they can flip open and check quickly.

---

Shinobi 7 — The 7-Inch Step Up

The Shinobi 7 increases screen real estate to 7 inches at 1000 nits. More visible detail for critical focus and exposure monitoring without stepping up to a heavier, more expensive field monitor category.

Key specs:

• 7-inch IPS display, 1920×1200
• 1000 nits peak brightness
• HDMI input (up to 4K/60)
• SDI input on SDI models

Best for: Documentary and interview productions where a larger monitoring surface aids the operator, director's monitor position on a follow focus rig, any setup where the 5-inch Shinobi feels cramped for critical work.

---

Shinobi 7 RX — 7 Inches with USB-C Camera Control

The Shinobi 7 RX adds one significant capability over the standard Shinobi 7: USB-C camera control. Connect a compatible camera to the Shinobi 7 RX via USB-C and control camera parameters — ISO, shutter speed, aperture, focus, white balance — directly from the monitor's touchscreen.

Key specs:

• 7-inch IPS display, 1920×1200
• 1000 nits peak brightness
• HDMI and 3G-SDI inputs
• USB-C camera control — compatible with Sony, Canon, Nikon, Fujifilm, and other major brands

Best for: Solo operators running compact rigs who want to control camera settings without reaching back to the camera body — particularly powerful on gimbals where the camera is physically inaccessible during a shot. Reduces the number of cables and control surfaces needed in a minimal rig.

---

Shinobi SDI Models — Adding Broadcast Connectivity

Several Shinobi models are available in SDI versions alongside HDMI-only versions. The SDI models add a 3G-SDI input for connecting professional broadcast cameras, and some include SDI loop-through for passing the signal to a downstream device (a recorder, a second monitor, or a switcher) without interrupting the monitoring feed.

Best for: Any production mixing broadcast SDI cameras with a monitoring workflow, ENG rigs using SDI cameras, productions that need to pass signal through the monitor to other devices.

---

Quick Comparison

All Shinobi monitors available at videoguys.com. Call 1-800-323-2325 for help choosing the right model for your rig.
