Essential Guide to PTZOptics UVC Control Software
The PTZOptics UVC Control is a remote control for your camera that you can access from any computer or device on your internal network.
Top features:
- Video & PTZ Control with 1 USB Cable
- Up to 500 presets
- WebRemote – Use on any computer/smartphone
- PresetVisualizer- A visual layout of your camera presets
- Use up to 8 cameras with one computer!
- IPRemote- Remote camera controls via IP
- Free trial available upon request
- Keyboard Controls
- VISCA Control Version Coming Soon!
Under the hood you will find access to advanced features such as: a camera manager, web server and preset visualizer which we will talk about in the “advanced features” section below. The top portion of the GUI interface includes a “Home” button along with 8 direction keys, which you can use to control your camera with a mouse, keyboard or USB joystick. Below the control section you have access to zoom and focus controls along with a camera selection bar. Yes, this software can control up to 8 cameras with one computer! Next, we have control of the presets which include the ability to name presets.
Presets
One of the most important features is the ability to name presets. Once your presets are named, others can pick up where you left off easily. Below the presets we have the “PTZVisual” which open the PTZVisual layout tool. This includes the ability to have live video preview (with a connected USB camera) or take a room snapshot to use for setting up visual presets. Below the PresetVisualizer we have “Web Control” which allows you to turn on/off your webhosting which allows other computers and smart phones to take camera control. Finally we have SkyPTZ which is a service that allows you to provide far end camera control outside your network.User Insights
The best way to grasp how people are using this technology is to look at a few examples of the PTZ-Visual in action. In essence the PTZ-Visual can be used with any photo (ideally the room you are using your camera in) to overlay your preset positions visually. For use in a conference room or distance learning/classroom setting the ability to add headshots with name tags is also available. Once you have your room photo in place and your presets lined up you only have to align your camera presets with the actual corresponding locations and your done.
Let’s look at the classroom example in the gif to the left (enlarge image if you need to). Actual student photos can be used and placed as preset or we can simply mark out the important areas for a distance learning video call. Since we are using a USB camera with UVC control we can assume that we are using a cloud based video conferencing software like Adobe Connect. The PresetVisualizer is our visual layout of the cameras views we will want to use during our video call. One preset is on a SmartBoard, another is on the teachers podium and another is on the classroom full of students. If we have multiple cameras in use we can use select between them in the main panel and use the visualizer to easily select between presets.
Let’s take the conference room example where we have 8 people sitting around a table on both sides of a video call. The PresetVisualizer can be used to allow users from both sides of the video call to easily select who they want to see on the main screen. This set up works well for telepresence and video conferencing applications.
Let’s take the conference room example where we have 8 people sitting around a table on both sides of a video call. The PresetVisualizer can be used to allow users from both sides of the video call to easily select who they want to see on the main screen. This set up works well for telepresence and video conferencing applications.
Taking things a step further we also support keyboard control. Keyboard camera control is useful to simply the devices you need to operate the camera while still providing a easy user interface. All you have to do is enable the keyboard control (careful to un-enable it when you done) to turn on the keyboard for camera controls.
Download the UVC Control App Datasheet.
