How Wirecast Works: The Interface, 5-Layer System, and Shot Building Explained
Wirecast's interface is built around a logic that makes professional live production learnable fast — but understanding the layer system is what separates operators who use it well from those who fight it. Here's how it actually works.
Watch the overview: Wirecast Live Streaming Video Guys Live →
The Four Interface Zones
Properties panels (left) — audio and video properties, effects, and source settings. Where you go to fine-tune individual sources before they go live.
Preview pane (green) — your workspace. This is where you build and proof shots before committing them to the live output. Think of it as your staging area — nothing here is visible to viewers yet.
Live pane (red) — your program output. What's in here is what your audience sees. The separation between preview and live is what gives you the confidence to prepare a shot without accidentally broadcasting it.
Shot/layer area (bottom) — the 5-layer composition system. This is where Wirecast's production logic lives.
The 5-Layer System — Why It Matters
Wirecast uses five master layers for building compositions. What's on a higher layer covers what's below it. The recommended layer convention:
| Layer | What Goes Here |
|---|---|
| Layer 1 | Title cards, full-screen graphics |
| Layer 2 | Logos, lower thirds, scoreboards, text |
| Layer 3 | Video sources (cameras, NDI feeds, screen capture) |
| Layer 4 | Audio sources |
| Layer 5 | Backgrounds |
Why does this matter? Audio on Layer 4 plays through everything — it doesn't get cut off when you switch video sources on Layer 3. Your lower thirds on Layer 2 persist independently of your camera cuts. Your background sits behind everything without interfering with your switching. Each element of your production lives on its own layer and behaves independently.
Drag and drop to reorder. No menus, no mode changes.
Adding Sources — The Plus Button
Every layer has a plus (+) button. Click it to add any capture source to that layer:
- Video capture — capture cards, webcams, DSLR/mirrorless via USB
- NDI devices — any NDI camera or source on your network appears automatically
- Screen capture — full desktop, specific application window, or browser tab
- Media files — pre-recorded video, logos, lower thirds as image files
- Network devices — IP cameras via RTSP
- Backgrounds — static images or looping video backgrounds
Sources are added to whichever layer you want them on. The layer convention above keeps your composition organized and switching clean.
Output Settings — 23 CDN Presets Built In
Wirecast's output settings include preset configurations for 23 major CDNs — YouTube, Facebook, Twitch, LinkedIn, and more. Each preset contains the platform's recommended resolution, frame rate, and bitrate. You don't need to look up what Facebook prefers or what YouTube recommends. Select the platform, select the preset, stream.
Beyond presets, Wirecast supports RTMP, SRT, NDI out, and virtual camera output — meaning you can use Wirecast's full production value (lower thirds, multi-camera switching, guest integration) as the video source in Zoom, Teams, or Google Meet.
Switching — How It Works in Practice
Once your layers are built, switching is straightforward: click a shot in the preview pane to stage it, then click Switch (or use a keyboard shortcut or Stream Deck button) to push it live. Transitions — cuts, dissolves, custom animations — are assigned per switch.
For sports productions using PTZ presets, switching becomes even faster: preset buttons recall camera positions, and switching between them requires no manual pan/tilt/zoom operations at all.
