PTZOptics NDI Cameras and NewTek TriCaster TC1 Can Enhance Your Production
In this video guide, Paul Schmutzler demonstrates how to use PTZOptics Cameras with built-in NDI support can be paired with the NewTek TriCaster TC1 to enhance your live productions. NDI is NewTeks open sourced network device interface protocol. PTZOptics cameras can now support it. What this means is, you can connect these cameras to the TC1 with just an Ethernet cable. POE switch can run these cameras with just one cable!
Click here to watch the video on YouTubeIn this tutorial, I’ll show you how the newest gear from NewTek and PTZOptics can take your sports production game to the next level. At the 2017 NAB show, NewTek introduced the 4K 60P TriCaster TC1 with NDI support (Figure 1, below). NDI is NewTek's open-source network device interface protocol. Figure 1. NewTek TriCaster TC1 PTZOptics cameras (Figure 2, below) support it. What this means is that you can easily connect their cameras to the TC1 with just an ethernet cable for control and signal. Figure 2. PTZOptics cameras I took the TC1 and some PTZOptics cameras to a local high school football practice to test out a setup. PTZOptics offers a variety of cameras to fit your needs. Since I was shooting from a long distance, I chose PTZOptics 20x models with 20X zoom for following the action. With a power-over-ethernet switch, I could run these cameras with just one cable. Key Features of PTZOptics Cameras for Sports Shooters In most sporting arenas, PTZOptics cameras are permanently mounted with a wall, ceiling, or pull mount. In fact, many customers choose to use an outdoor camera housing for permanently installed outdoor locations. For this demo, I'm using a trusty tripod (Figure 3) Figure 3. PTZOptics 20x-SDI on tripod The fast pace of sports requires high frame rates for smooth motion. I've used NDI to set the camera frame rates to 59.94 and the shutter speeds to 1/120 (Figure 4, below). Figure 4. Choosing settings for the PTZOptics 20x As you can see in Figure 5 (below), the video quality is just as good as traditional over-the-shoulder broadcast cameras. But I can remotely control all my PTZ cams from a single location. Figure 5. High school football captured with the PTZOptics 20x For a wide shot of the field and stadium, I set up the Z-cam variable lens (Figure 6, below).....[Continue Reading]
