Awarding-winning multi-format conversion technology concentrated in a simplified mini-converter.
Roland's new video converters address the demand for high-quality, lossless video and audio converters for live/post production as well as installed systems. They include the:
Uncompromising commitment to picture quality.
The VC-1 series faithfully converts the original source with no change in color or brightness. It supports super-blacks and super-whites, and converts video from cameras and other source devices with all the originality intact.
The VC-1 series features an on-board reclocker to compensate for
attenuation of SDI signals carried over long distances. This makes it possible to receive camera-relay video while maintaining a high image quality.
Faithful reproduction of video characteristics.
The VC-1 series reproduces the video characteristics of the original source with no interlace artifacts, pixel shifting, or other conversion problems or signal errors. Jitter and return loss are at exceptional levels as well.
Support for 1080p 3G-SDI.
Video signals beyond 1080i can be input and output. The VC-1 series supports both level A and level B 3G-SDI, letting you connect a wide variety of 3G-SDI equipment. 1080i, 720p, and SD signals are accommodated automatically on connection.
High quality and rugged construction for the rigors of front-line use.
High quality, smart design.
The exterior plating is aluminum at 2 millimeters thick. The connectors laid out inside the exterior plates are fastened to the chassis with nuts and bolts. This makes for a heavy-duty specification that can keep the connectors from coming loose even with frequent cable changes, as well as withstanding impact and drops. Every connector has an LED input indicator enabling you to confirm the status of signal transmission at a glance. The series is built for uncompromising reliability that includes accurate operation even over long periods of continuous use thanks to a design featuring exceptional heat-radiating efficiency.
A form factor that accommodates use on-the-go.
Cutaway areas in the exterior plate enable you to fasten the unit to tripods or the like using velcro or elastic ties. This makes for convenient placement and setup even during live on-site use.
Support for HDCP HDMI signals.
The VC-1 series is compliant with HDCP. For example, the VC-1-DL can take HDCP-applied HDMI input signals, apply frame synchronization or delay, and produce HDCP-applied HDMI output. This allows the VC-1 series to be used in any HDCP-based system with no worries.
Support for workflow combining audio and video.
Audio embedding and de-embedding features are provided (channel-selectable) in the VC-1 Series. The audio embedding feature lets you place audio signals from a different source into the video output. For example, when converting an SDI signal to HDMI, you can use the audio embedding feature to output high-quality audio from any of the SDI audio channels. Digital (AES/EBU) input and output are also supported, letting you exchange sound between professional audio equipment with no degradation in signal. Analog input and output is supported as well making it possible to both monitor and input audio to/from a wide variety of equipment such as an audio console.
Easy configuration with DIP switches or dedicated PC/Mac software app.
DIP switches make it simple to accommodate on-site requirements. Change the conversion direction or other settings by simply sliding a DIP switch on the side of the unit. Delay Dials (VC-1-DL only) set the amount of delay for video and audio. Set the amount of delay independently for video and audio in a range of 0 to 9 fields (0 to 4.5 frames). Connection to a computer via USB cable unlocks even greater versatility with advanced settings including a memory location to lock in a favorite configuration. Control and configure multiple VC-1 units at the same time using a USB hub.
All-in-one Standard Definition video mixer with HDMI in/out, USB streaming out, and built-in multiviewer with touch control. Accessible and quality video performance and web streaming - The V-4EX - advancing the legendary V-4 and V-8 family to now include HDMI in/out, progressive internal processing, audio embedding, USB streaming and built-in touch monitor. The Roland V-4EX advances the industry-standard Roland V-4 four channel video mixer by incorporating HDMI inputs/outputs, USB streaming, HDCP support, built-in touch multi-viewer, and audio embedding. These features are added to the strong primary feature set including built-in effects and unique user interface that has made the V-4 one of the besting selling video mixers of all time.
AV Mixer with Live Streaming
The VR-3’s innovative design incorporates a video switcher, audio mixer, preview monitors and streaming-ready USB output all in a single unit. As a USB Video/Audio class device, web streaming is effortless by simply connecting to a computer running a live streaming service such as USTREAM , Livestream, Stickam, Justin.tv, worshipstream.com, websharelive.com, etc. The reduction in hardware equipment, setup time and connection complexity ensures a worry-free, easy to use solution for any event.
AV Mixer and Recorder
The VR-5’s “all-in-one” solution greatly simplifies production, recording and streaming of any live event. The VR-5’s innovative design incorporates a video switcher, audio mixer, video playback, recorder, preview monitors and output for web streaming all in a single unit. As a USB Video/Audio class device, web streaming is effortless by simply connecting to a computer running a live streaming service such as Livestream, USTREAM, ClickStreamTV, justin.tv, Stickam, and others as well as any video call service such as Skype and iChat. The reduction in hardware equipment, setup time and connection complexity ensures a worry-free, easy to use solution for any event.
AV Mixer with USB 3
A complete portable HD studio in a single unit. Single-person operation of sound and picture using faders, buttons and touch screen. The Roland VR-50HD all-in-one AV mixer beautifully integrates an audio mixer, video switcher, multi-viewer touch screen and USB video/audio streaming into a stand-alone device. This single unit delivers functionality that until now required a number of peripheral devices to accomplish. This portable live HD production solution is ideal for schools, churches, council meetings, corporate events, sports, trainings, or any other live event.
Attention Schools, Organizations, Government Agencies, and House of Worship:
Call us 800 323-2325 to see if you qualify for a 5% discount!
Roland video mixers, from standard to high definition, have been used widely in the education market for live production switching at events, morning news programs, PAC meetings, etc. Ease of use, reliability and affordability make them de-facto standards amongst educators. Educators need to stay current with technology to ensure that students are ready to apply their skills to real world applications. Roland video products are reliable, easy to use, and affordable making them the Educators choice.
