YoloBox Extreme Visual Production Tools: LUTs, Custom Layouts, Telestrate, and Audience Engagement

Firmware updates have significantly expanded the YoloBox Extreme's visual production capabilities — from color science tools to audience interaction features. Here's what's been added and how to use it.

Watch the live demo: YoloBox Extreme visual tools on Video Guys Live →

LUT Support — Color Matching Across All Cameras

LUTs (Look Up Tables) are color profiles you apply to video sources to achieve a specific look or to match cameras that have different color characteristics. The YoloBox Extreme now supports LUT application per source, in real time.

How to apply a LUT:

1. Hold any source in the input list
2. Select "Add LUT"
3. Browse LUTs loaded from SD card or USB drive
4. Toggle them on/off to compare in real time
5. Tap Done to apply

You can apply the same LUT to every camera in your production simultaneously — giving your show a consistent, intentional color grade before it ever reaches a streaming platform or editing timeline.

LUTs are widely available online, many for free (Shutterstock, community resources, camera manufacturer profiles). Download, load onto an SD card, import into the YoloBox.

Why this matters for single-operator productions: Camera matching has historically required a colorist in post. Applying a matching LUT to all sources in the YoloBox means your live stream already looks color-consistent — no post work needed for the program output.

Custom Layout Builder — Build Your Show in Minutes

The YoloBox Extreme includes a custom layout builder accessible from the Add Video Source menu. Recent firmware updates added more pre-made layouts (including additional three-way splits) and new customization tools.

Building a layout:

1. Add a background — from internal storage, SD card, or USB drive
2. Add video sources one at a time, placing them in z-order (lower layers go in first)
3. Resize and reposition each source by dragging
4. Crop — trim edges from any source (useful for removing unwanted content from camera edges or letterboxing)
5. Border radius — soften the corners of any source for a modern, polished look; set border color and weight independently
6. Save the layout and recall it with one tap during production

The custom builder replaces what previously required dedicated graphics software. A complete production layout — background, multiple cameras, properly cropped and composed — takes about two minutes to build on the touchscreen.

Telestrate and Annotate — Live Drawing on Your Broadcast

The Telestrate/Annotate feature lets you draw directly on your live output in real time — useful for sports analysis, educational content, presentations, or any production where you want to highlight something on screen.

How it works: Make any source full screen, then tap the Annotate toggle in the top left. Three tools are available:

• Laser pointer — a moving dot that highlights without leaving marks
• Persistent lines — draw shapes, arrows, or highlights that stay on screen until cleared
• Disappearing lines — marks that fade after a second, useful for quick callouts without cluttering the frame

All three are available simultaneously and switchable mid-annotation. Tap Annotate off to return to clean output.

Audience Engagement — Comments and Viewer Map

Comment display: Pull comments from YouTube, Twitch, or other streaming platforms and display them as on-screen overlays. Fully customizable:

• Show or hide commenter profile images
• Change font, font size, and font color
• Change background color and title styling
• Position anywhere on screen

Viewer map: Shows geolocation data of where your viewers are joining from, displayed as a map overlay. Interactive — if a viewer comments "Hello from Tokyo," you can pull their location up on the map and show the audience where they're watching from.

Both features are designed to increase viewer interaction and make remote audiences feel present in the production — particularly valuable for regular community broadcasts like worship services, sports, and recurring shows.

Quick Mode Streaming — From Power-On to Live Faster

Quick Mode now supports direct streaming — a significant update from the previous version where Quick Mode was monitoring and recording only.

Combined with the saved settings feature (previous event settings auto-load on new event creation), the workflow from device power-on to live stream is now:

1. Power on YoloBox Extreme
2. Create new event → tap "Use Previous Settings"
3. Enter Quick Mode
4. Tap Stream → select destination → go live

No rebuilding layouts, no reassigning cameras, no reconfiguring audio. For weekly recurring productions this is the difference between a 20-minute setup and a 3-minute setup.
