AJA 1-Channel 3G-SDI Single-Mode LC Fiber Transmitter

AJA FIBERLC-1-TX 3G-SDI Single-Mode LC Fiber Transmitter

The AJA FIBERLC-1-TX is a 1-channel 3G-SDI single-mode LC fiber transmitter SFP designed for compatible AJA fiber hardware. This compact, interchangeable SFP module provides a reliable way to transmit 3G-SDI signals over single-mode LC fiber, making it well suited for professional broadcast, production, and video infrastructure applications.

Key Features

• 1-channel 3G-SDI fiber transmitter
• Single-mode LC fiber connectivity
• AJA FIBERLC-1-TX SFP module
• Compact Small Form-factor Pluggable (SFP) design
• Supports SFP connections up to 4.25Gbps
• Designed for compatible AJA fiber hardware with SFP ports
• Interchangeable module design for flexible fiber configurations
• Ideal for professional video, broadcast, and production workflows

3G-SDI Single-Mode LC Fiber Transmission

The AJA FIBERLC-1-TX provides 3G-SDI signal transmission over single-mode LC fiber, allowing compatible AJA equipment to take advantage of existing fiber infrastructure. Its SFP form factor makes it easy to configure compatible AJA hardware for the fiber connection required by your workflow.

AJA SFP modules are designed as compact, interchangeable optical modules that can be installed in compatible SFP ports. Depending on the hardware and module, SFP solutions can support different connector types and optical transmission configurations.

Flexible Fiber Connectivity for AJA Systems

AJA offers a range of fiber-capable products that use SFP technology to provide flexible connectivity options. Compatible AJA hardware can use SFP modules for applications including video transmission, recording and playback, frame synchronization, and signal conversion.

The FIBERLC-1-TX 3G-SDI Single-Mode LC Fiber Transmitter is a practical choice when you need to add single-mode LC fiber transmission to compatible AJA equipment. Its interchangeable SFP design also makes it easier to adapt your fiber infrastructure to the requirements of different professional video systems.

• Product Type: Fiber Transmitter SFP Module
• Signal Support: 3G-SDI, HD-SDI, SD-SDI
• Channels: 1 Channel
• Fiber Type: Multi-Mode Fiber (MMF)
• Connector Type: LC
• Direction: Transmitter (TX)
• Form Factor: Hot-Swappable SFP
• Compatibility: AJA FiDO Fiber Converters
• Application: Broadcast, Live Production, Professional AV

• AJA FIBERLC-1-TX 3G-SDI Single-Mode LC Fiber Transmitter
• Warranty: Limited 5-Year Manufacturer Warranty
