IMAGING
Image Sensor
1 / 2.86 inch CMOS 2.2MP
Lens
4.7-47mm
Optical Zoom
10x
Digital Zoom
12x
Horizontal angle of view
60.9° (W) – 6.43° (T)
Aperture
F1.6 (W) – F3.0 (T)
Minimun Illumination
Color: 0.5 lux
Shutter Speed
1/1 – 1/30000s
Filter Ring
49mm
Focus
Auto, Push, Manual
White balance
Auto, Indoor, Outdoor, Manual, OPW, ATW, Temp (Kelvin)
Exposure
Auto, Manual, Shutter/Iris Priority
Backlight Compensation
Yes
MECHANICAL
Pan Movement
Horizontal: ±175º (Zoom Adaptive Speed Range: 0.5°〜100°⁄s)
Tilt Movement
Vertical: +90° to -30° (Zoom Adaptive Speed Range: 0.05°〜72°⁄s)
Preset Positions
128 (Speed adjustable: Up to 150°⁄s)
Preset Speed
0-5 Level Adjustable
Environmental
Indoor
Operating Temperature
-10 – +50 (°C)
Operating Humidity
≤80%
Operating Noise
Max 41dB at full speed pan
Tally display
Bi Colour Full overhead and rear (w/included 0-9 number silicon plugs)
ONBOARD DISPLAY
Onboard OLED display
5-line, RGB Color, Graphical
VIDEO INTERFACE
Video Output
NDI/SDI/HDMI/USB2.0(UVC)
Video Format support
1080p 60, 59.94, 50, 29.97, 25 - 1080i 60, 59.94, 50 - 720p 60, 59.94, 50
AUDIO I/O (via USB breakout cable) Limited Resolution support over USB
3.5mm Audio In (Stereo)- 3.5mm Audio Out (Stereo) - (NDI, SDI, and HDMI only)
CONTROL INTERFACE
IP Control
NDI Control (auto configuring), VISCA IP
Serial PTZ control
1x RJ45: RS232/RS422
Serial Control Protocol
VISCA / PELCO D
Software control
Included Cam Control (Win 10.+) Realtime subject motion tracking control (AI)
POWER & DIMENSIONS
Power Input
12v DC, PoE+ (IEEE 802.3at)
Dimensions
145x152x171mm
Weight
1.0Kg
NETWORK
Video Compression
Full NDI – i-frame high quality low latency NDI for production
h.264 long-GOP (Limited resolution support)
Network Protocol Support
NDI – Discovery, configuration and control
NDI | HX2
SRT
Cloud Connect
RTSP
RTMP
Web Control Interface
Full control via Web/Mobixle UI including Scene presets
