NETGEAR M4250-10G2F PoE+ AV Switch with 125W Total Power Delivery
$779.95$499.99
2
VideoGuys Part # (SKU): GSM4212P100NAS
MFR Part # (MPN): GSM4212P-100NAS
NETGEAR M4250 10G2F PoE+ AV Switch
  • Full Description
  • Specifications
  • What's Included
  • Demo Videos
  • Reviews
We recommend the Netgear AVLine switches for any live production workflow with NDI. The NETGEAR M4250-10G2F is an affordable solution for getting started with NDI and is easy to configure and use. The POE+ capability is enough to power your PTZ cameras and NDI converters.
Highlights
  • 8x1G PoE+
  • TPD 125W
  • 2x1G
  • 2xSFP
The NETGEAR M4250 AV Line of switches are engineered for 1G AV over IP and designed for clean integration in a rack, under a table, or behind a display and including a unique NDI® profile already configured for you.

Extended AV features
  • Dedicated AV web-based GUI
  • interface for more specific AV installations
  • Color-based AV profiles can be applied to the different ports
  •  Dante, Q-SYS, AES67 and AVB audio profiles
  • AVB requires a license (sold separately)
  • NVX, SVSI, Q-SYS, NDI and Dante video profiles
  • Audio / video / control mixed profiles
  • Automatic switch interconnect with NETGEAR Auto-Trunk, Auto-LAG and IGMP Plus
  • Common Layer 2 and Layer 3 switching engine across all M4250 models
  • Built-in IT web GUI, console, telnet and SSH consistent with other
  • NETGEAR M4300 and M4500 series Feature set includes static, RIP and PIM routing, DHCP Server and PTPv2
Audio Video Bridging (AVB) services
  • AVB is one of the many features designed into the M4250 product line
  • AVB is an industry standard for transporting content over a network
  • AVB is used most often when very low latency is required such as in live
  • performances when lip sync is critical
  • All of the AV Line M4250 switches can be optionally licensed for AVB support

Other IT use cases
  • Standard or recessed mounting with all ports in the back, or all ports in the front
  • Fully featured L2/L3/L4 platform for midsize Enterprise campus networks, IoT and IPTV
Industry standard management
  • Industry standard command line interface (CLI), main NETGEAR IT web interface (GUI), SNMP, sFlow and RSPAN
  • Single-pane-of-glass NMS300 management platform with centralized firmware updates and massconfiguration support
M4250-10G2F-PoE+

  • 8-port 10/100/1000BASE-T (RJ45) PoE+ with 125W PoE budget
  • 2-port 10/100/1000BASE-T (RJ45)
  • 2-port 1000BASE-X (SFP)
  • 24 Gbps non-blocking fabric across 12 ports
  • Out-of-band 1G Ethernet management port
  • USB-C and RJ45 RS232 console ports and USB-A storage port
  • Front black display panel and all ports in the back
  • Possible reversed mounting with ports in the front
  • Rack-mounting standard brackets
  • Longer brackets for recessed mounting (2 inches / 5 cm)
  • Threaded hole in front (1xM10) for clamps
  • Threaded holes on the bottom (4xM5) for 50x100mm VESA plates
  • Selectable fan modes for fanless, quiet, or cool operation

TECHNICAL SPECS

  • Primary Port Speed : 1 Gigabit
  • Number of Ports : 12 (10x 1G, 2x SFP)
  • PoE Ports / Budget : 8 PoE+ (30W/port), 125W Budget
  • IGMP Support : Enhanced (NETGEAR IGMP Plus™)
  • Jumbo Frame Support : Yes, up to 12kb
  • Acoustics : Fanless or 30dB@25ºC
  • Power Consumption : With PoE: 163.9W/559.555Btu/hr; Without PoE: 17.32W/59.13Btu/hr; Standby without any port connection: 8.53W/29.121Btu/hr
  • AVB Support : Yes. Electronic license required, activation key sent via email (AVB4212P-10000S)

PHYSICAL SPECIFICATION

  • Dimensions (WxDxH) : 440 x 200 x 43.2mm
  • Weight : 2.85Kg (6.28lb)
  • M4250-10G2F-PoE+ (GSM4212P)
  • Power cord(s)
  • Console USB Type-C and RJ45-DB9 cables
  • Rack-mounting standard brackets
  • Longer brackets for recessed mounting
  • Rubber footpads for tabletop installation
  • Installation guide
