NETGEAR MS110TX 8-port Multi-Gig Ethernet Smart Managed Switch with 2 10G SFP+ Ports

NETGEAR MS110TX 8-port Multi-Gig Ethernet Smart Managed Switch with 2 10G SFP+ Ports

Key Features:

• Ports: 10 Ports
• Port Types
  • 8x 1G/2.5G copper ports
  • 2x 10G SFP+ fiber uplinks
• Details
  • 8 x 2.5G ports for faster WiFi
  • 2 x 10G SFP+ uplinks to core
  • PD-capable port for flexible power
  • Fanless, silent operation
  • NETGEAR Insight cloud management
  • Desktop, wallmount, or rackmount
  • Limited lifetime warranty, Fast RMA replacement

Built on your feedback. Designed for the way you work.

NETGEAR Insight 10.0—a smarter, simpler way to deploy, monitor, and manage your network.

PD-CAPABLE PORT

Port 1 can power the switch over Ethernet from an upstream source, simplifying placement where outlets are scarce.

FLEXIBLE MOUNTING

An 11-inch enclosure (253 x 180 x 44mm) installs on a desk, with VESA wallmount holes, or in a rack with kits.

FANLESS AND SILENT

No fans means no noise and one fewer moving part to fail, so the switch fits noise-sensitive spaces.

LITE L3 FEATURE SET

LANs, QoS, ACLs, STP/RSTP/MSTP, SNMP, Static Routing, DHCP Server/Relay, IGMP and MLD snooping, LACP, IPv4/IPv6 management, and LLDP-MED.

INSIGHT CLOUD MANAGEMENT

Configure, monitor, and troubleshoot from a phone or browser, so one team can manage many sites without site visits.

SMART CLI

Scriptable control through a direct serial connection or a remote logical connection with telnet or SSH, providing rapid deployment at scale.


• Width: 253mm
• Depth: 180mm
• Height: 44mm
• Weight: 1.48kg
• Speed: 2.5G
• 1G/2.5G ports: 8
• 10G SFP+ ports: 2
• MAC Table Size: 16K
• Packet buffer size: 1.5 MB
• VLAN (Number Supported): 256
• VLAN routing: Yes
• Dynamic VLAN assignment: Yes
• MLD Snooping: Yes
• Static route: Yes
• Host ARP table: 1024
• EEE: Yes
• DoS Prevention: Yes
• Internal/External Power Supply/Adapter: External
• Max consumption (Watts): 16.4W
• FAN: None, fanless
• Acoustic Noise Level @25C (dBA): 0dBA
• Operating Temperature: 0° to 40° C
• MTBF: 1,843,597 hrs

• NETGEAR MS110TX with Insight Cloud Management
• Power adapter (varies by region)
• Rackmount kit
• Rubber footpads for tabletop installation
• Installation Guide
• Warranty: This product is backed by NETGEAR limited lifetime hardware warranty.
