New Professional-use PTZ Camera: New Standard for Video Expressiveness and Operational Versatility
Panasonic's new 4K PTZ camera (AW-UE150AW/AK) meets the demands for advanced video production by setting new standard for video expressiveness and operational versatility. Building on its predecessor, the widely used AW-UE150W/K released in 2018, the AW-UE150AW/AK introduces new capabilities for enhanced video quality and flexible operation. In addition to improved pan, tilt, and zoom synchronization, it supports NDI® High Bandwidth for optimal remote-production workflows.
The AW-UE150A 4K PTZ camera has been designed to meet the needs of professional broadcasters and content creators, delivering advanced video quality, operability and eciency in studio-based video productions.
Exceptional Performance for Capturing Immersive Moments
- Large Sensor for High-quality Video Shooting
- Superior OIS and PTZ Control for Smooth, Natural Video
- Equipped with moiré reduction function by optical low-pass filter
Flexible Adaptation to Diverse Environments
- Wide-angle Lens (75.1° horizontal) with 20x Optical Zoom
- Compatible with Panasonic Remote Operation Panel
- NDI® High Bandwidth and NDI® HX2 Supported as a standard feature
- SRT Support for Stable video transmission over public lines
Advanced Features for Expanded Creative Possibilities
- Compatible with FreeD for AR/VR Systems
- Compatible with V-Log
- Cropping Function
- Quickly Capture the Speaker with the Built-in Auto Tracking Function
- Three-color Tally Lamp
- Compatible with Panasonic software
- Compatible with IT/IP platform "KAIROS"
General
Power Requirements
DC 12 V (10.8 V to 24.0 V)
PoE++
IEEE802.3 bt standard: DC 42 V to 57 V (Software authentication (LLDP) is supported).
Current Consumption
4.0 A (XLR IN connector), 1.2 A (PoE++ power supply)
Ambient Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
Ambient Operating Humidity
20 % to 90 % (no condensation)
Storage Temperature
–20 °C to 50 °C (–4 °F to 122 °F)
Mass
Approx. 4.3 kg (9.48 lbs) (excluding mount bracket)
Dime(more...)
