Teradek Prism 877 4K 10-bit 12G-SDI HEVC/AVC Encoder/Decoder Card

Teradek Prism 877 4K 10-bit 12G-SDI HEVC/AVC Encoder/Decoder Card

The Teradek Prism 877 is a professional 4K 10-bit 12G-SDI encoder/decoder card designed to expand the capabilities of compatible Teradek Prism Rack systems. Supporting up to DCI 4K60 10-bit 4:2:2 video, the Prism 877 combines H.264/AVC and H.265/HEVC compression with flexible encoding and decoding capabilities for live production, broadcast, streaming, and IP video workflows.

Key Features

• Supports up to DCI 4K60 10-bit 4:2:2 video
• Two 12G-SDI ports for loop, decode, or encode/decode workflows
• H.264/AVC and H.265/HEVC compression support
• Optional license enables bidirectional encoding and decoding
• Built-in video scaling and deinterlacing
• HDR support for 2020-PQ, 2020-HLG, and P3D65-PQ
• Supports 8-channel audio
• Supports up to 10 video overlays
• SRT, RTMP, and RTSP support for IP video and streaming workflows
• Camera-to-cloud ready
• Record to SD card or built-in 256GB NVMe storage

4K 10-bit 12G-SDI Encoding and Decoding

The Prism 877 delivers high-quality video processing for demanding professional workflows, supporting resolutions up to DCI 4K60 with 10-bit 4:2:2 color. Its H.264/AVC and H.265/HEVC compression capabilities provide efficient video delivery while maintaining image quality and helping minimize latency.

Two 12G-SDI ports can be configured for loop, decode, or encode/decode applications. With an optional license, the card can also support simultaneous bidirectional encoding and decoding for more advanced production workflows.

HDR and Professional Video Processing

Built-in processing features make the Prism 877 adaptable to a wide range of video sources and production environments. The card supports HDR formats including 2020-PQ, 2020-HLG, and P3D65-PQ, along with video scaling and deinterlacing.

The Prism 877 also supports 8-channel audio and up to 10 video overlays, providing additional flexibility for live broadcast, streaming, and contribution applications.

Streaming, Camera-to-Cloud and Recording

Designed for modern IP video workflows, the Prism 877 supports SRT, RTMP, and RTSP, making it suitable for streaming, remote contribution, and camera-to-cloud applications.

For recording and backup, video can be captured to an SD card or the built-in 256GB NVMe storage. Optional licenses can further expand the system with capabilities such as network bonding and multi-output support.

Expand Your Prism Rack

The Teradek Prism 877 4K 10-bit 12G-SDI encoder/decoder card adds flexible 4K video encoding, decoding, processing, streaming, and recording capabilities to compatible Prism Rack systems. It is a powerful solution for professional live production, broadcast, event streaming, IP video, and remote production workflows.

• Network Bonding: 2 Bonding Sources
• 4K DCI 10-bit 4:2:2: Yes
• On-Board Protocols: DASH, HLS, MPEG-TS, RIST, RTMP(S), RTP Push, RTSP, SRT, TRT, WHIP
• User-Selectable Encoder or Decoder Mode: Yes
• Storage: NVME / SD Card
• Licenses:
  • Multi-Output
  • Debonding
  • Decode

• Teradek Prism 877 4K 10-bit 12G-SDI HEVC/AVC Encoder/Decoder Card
• Warranty: Limited 1-Year Manufacturer Warranty
