Vizrt TriCaster Mini S Software Subscription

Network Video Input
8 x total IP video inputs via NDI®, resolution-independent NDI inputs supporting video input in any combination of standard formats, resolutions, and frame rates1
• 2160p 59.94, 50, 29.97, 25
• 1080p: 59.94, 50, 29.97, 25
• 1080i: 59.94, 50
• 720p: 59.94, 50, 29.97, 25
• SD: 59.94, 50, 25 1 Available frame rates determined by session video standard (NTSC or PAL)

PTZ
Support for up to 8 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial and network protocols, including RS232, RS422, and IP, with integrated controls and preset system. Control connections will vary based on hardware.

Skype TX
Native support for up to 2 simultaneous Skype® video call inputs via Skype TX software integration, including tally and Talk Back communication

Network Video Output
IP video output via NDI, optionally configurable for:
• 4 x independent video mix outputs
• 1 x UHD video mix output

Stream Output
2 x resolution-independent streaming video outputs, independently configurable and controllable, with simultaneous stream archive

Monitor Outputs
UI and multiview outputs available via onboard GPU outputs

Mix/Effect Buses (M/E)
4 x M/E buses supporting video re-entry
• 1 x Mix/Effect channel per bus with support for up to 2 sources
• 2 x KEY layers per bus

DSK Channels
2 x DSK channels

Media
4 x media players
• 2 x DDR
• 1X GFX
• 1 x Sound
15 x media buffers
• 5 x animation buffers including GIF support
• 10 x graphic buffers

Keyers
Integrated LiveMatte™ chroma and luma keying technology on all source channels
and M/E buses
• 8 x input keyers
• 2 x media player keyers
• 4 x M/E keyers
15 x buffer keyers

COMPs
Integrated video composition engine on the switcher and each M/E bus to create, store, and apply layer configurations and DVE-style motion sequences
16 x configurable COMP presets per bus

Virtual Sets
Integrated LiveSet™ technology with 30+ live virtual sets and box effects included

DataLink
Integrated DataLink™ technology enabling real-time, automated data input from internal and external sources, including webpages, spreadsheets, scoreboards, databases, RSS feeds, watch files, XML, CSV, ASCII and more

Macros
Record, store, edit and automate commands and user-configured operation sequences
• Attach to control panel buttons, keyboard shortcuts, hotspots, MIDI and Xkeys® buttons or GPI triggers
• Attach to internal events and state changes, including audio, media playback, tally and specific switcher action
• Supports control via web-based interface

Recording
4 x recording channels from either NDI® inputs or Mix outputs
• Records and retains alpha channel data
• 4 x QuickTime® archival video recorders (Native NDI Codec for recording)2
2 QuickTime Player not required for playback in common NLE applications

Signal Monitoring
Integrated waveform and vectorscope, full field rate with digital calibration, color preview and support for ITU-R Rec. 709

Grab
Grab full-resolution, deinterlaced still images from external video sources and outputs

Export
Export video and image files to social media, FTP, local or external volumes, and network servers, with optional transcoding

Audio Mixing
Integrated multi-channel audio mixer with support for stereo audio, and DSPs

Network Audio
• Native support for network audio input and output via NDI®
• Embedded audio supported for all NDI® input and output video signals
• Integrated support3 for Dante™ networking protocol from Audinate®
3 Requires Dante Virtual Soundcard license from Audinate (sold separately)
5 Requires third-party virtual sound card license (sold separately)

Supported Media File Formats
Import, store, and play back multimedia files, with optional transcoding, including:
• Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM, and more
• Image: PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP, and more
• Audio: AIFF, MP3, WAV, and more

Processing
Video: YCbCr + Alpha color space, using 4:2:2:4
Audio: Floating Point, 96 kHz

Latency
Processing Latency: ~1.0-1.5 frames

Tally
Support for network tally via NDI®

MIDI
Support for standard MIDI protocol enabling third-party device control

HTML 5 Graphics 2 Users
2GB Asset Library
1 Output
1 Team
Graphics Editor
• Timeline-based Animations
• Text Crawler
• Assets Library
• 140 ready-to-use free graphics
Data Integrations
• Google Sheets Data Provider
• RSS / Atom Data Provider
• JSON REST Connector
• JSON WebSocket Connector
Security – MFA
Control API
Knowledge Base Support
Powered by Viz Flowics running in cloud, rendered locally via TriCaster Live Link.

Minimum System Requirements for TriCaster Mini S
• Must run Miscrosoft Windows 11
• Intel i7-12th Gen CPU (i7-12700 of greater recommended)
• NVIDIA Quardro T1000 8GB or greater or NVIDIA 3050 8GB or greater running the latest drivers
• 16GB RAM minimum
• 512GB SSD (M.2 NVMe recommended)
