Vizrt Viz Connect Studio I/O

Viz Connect Studio I/O
Viz Connect Studio IO is the ultimate in studio flexibility. Connect technologies, translate video, expand any workflow.

Built for NDI
Supporting 10Gb Ethernet, the Viz Connect Studio I/O is ideally placed for high-speed networking environments such as broadcast workflows and is perfect for NDI traffic. Built to work with NDI 6, it supports all the latest and upcoming features.

Broadcast Ready
2 RU Rack-mountable, the Viz Connect Studio I/O supports12G-SDI; the dynamic I/O set-up can be configured as 8 x 3G-SDI , 2 x 12G-SDI with 4 x 3G-SDI, or a wide range between. Support SDI ranging from SD to UHD including quad-link grouping and 6G-SDI is offered.

Adapts to your workflow
Viz Connect Studio I/O is a versatile solution combining IP flexibility with existing SDI infrastructure, audio integration for adaptable workflows, and channel management via local control, NDI KVM, or a web-based API.

Color Correction
Independently adjust the color characteristics of each channel, manually configuring brightness, contrast, hue, saturation, white balance, and more with integrated proc amp controls, or optionally enable automatic color matching between channels.

Configurable A/V Sources
Independently configure the video and audio for each channel, selecting from any source accessible to your Studio I/O Module.

Multi-Format Processing
Accept and deliver video in any combination of compatible formats, with resolution and frame rate configurable per channel.

NDI KVM
Access the user interface and control your Studio I/O Module remotely from any compatible computer, device, or touchscreen connected to the same network.

Remote Access
Monitor live signals and control your Studio I/O Module remotely from the browser of any networked device, including iOS and Android mobile devices, with a system-specific webpage.

• Video In: NDI®², SRT, SDI, RTMP, RTSP
• Video Out: NDI®, SDI
• IP I/O: Up to 8x
• SDI I/O: Up to 8x via HD-BNC
• 4K UHD SDI I/O: Up to 2x via 12G-SDI, 6G-SDI, or quad-link 3G-SDI
• Media Playback: Channels Up to 8x
• Recording Channels: Up to 8x SDI Inputs Only
• Supported Video Formats
  • 2160p: 59.94, 50, 29.97, 25, 24, 23.976
  • 1080p: 59.94, 50, 29.97, 25, 24, 23.976
  • 1080i: 59.94, 50
  • 720p: 59.94, 29.97, 25, 24, 23.976, 576i 50, 480i 59.94
  • 1080p: 60, 59.94, 50
  • 1080p/PsF: 30, 29.97, 25, 24, 23.98
  • 1080i: 30, 29.97, 25
  • 720p: 60, 59.94, 50
  • 576i: 25
  • 480i: 29.97
• Supported Media Formats
  • Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM, and more
  • Image: PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP, and more
  • Audio: AIFF, MP3, WAV, and more
• Audio I/O: Up to 8x SDI embedded
• Audio Networking
  • Native support for network audio input and output via NDI®
  • Embedded SDI audio supported for all NDI® input and output video signals
  • Support1 for Dante™, AES67, and ASIO protocols via compatible audio drivers
• Timecode: LTC and VITC
• Signal Monitoring: Integrated waveform and vectorscope, full field rate with digital calibration, color preview and support for ITU-R Rec. 709
• A/V Standards
  • 12G-SDI (ST 2082-10)
  • 6G-SDI (ST 2081-10)
  • 3G-SDI Level A (ST 425-1 Level A Mapping),
  • Quad Link 3G-SDI (ST 425-5),
  • HD-SDI (ST 292),
  • SD-SDI (ST 259)
• Video Processing: YCbCr + Alpha color space, using 4:2:2:4
• Audio Processing: Floating Point, 96 kHz
• Genlock: Reference input supporting SD (Bi-level), HD (Tri-level), or network (NDI) supported
• Multiviewer: Via HDMI or DisplayPort
• NIC
  • 1 x 10 Gigabit NIC (10GBASE-T over RJ45)
  • 1 x 2.5 Gigabit LAN
  • 1 x 1 Gigabit NIC (RJ45)
• System Physical
  • 2 RU chassis with 500W PSU
  • 19 x 3.5 x 19.57 inches (48.3 x 8.9 x 49.7 cm) with rack ears Rack rails sold separately

• Vizrt Viz Connect Studio I/O
• Warranty: Limited 1-Year Manufacturer Warranty
